The Division Chief

Stories

Overview

Tower Details

The Division Chief is a 36′ high fire training tower incorporating features from both the Lieutenant and the Assistant Fire Chief. With a footprint spanning 16′ wide x 36′ long, the Division Chief features seven rooms for the ultimate in training. The maze room, comprised of 12 movable, slide-able, and lockable partitions, allows training officers to challenge trainees time after time by redesigning the room into any configuration. The tower’s inset corner balcony offers a secure and realistic area to practice rappelling and laddering.

Endless Training Scenarios

Vertical Confined Spaces

Ventilation

Room Search / Clearing

Riser Operation

Live Fire Attack

Laddering and Rappelling

Helicopter Deployment

Forced Entry

Training Tower

3-Story
Tower

Dimensions	22’L x 16’W x 36’H
Roof	Flat
Roof Live Load	100 PSF
Wind Load	Per Local Codes
Deck Live Load	100 PSF

Included

Parapet Roof Guard with Chained Opening
Interior Stair to 4th Floor
Interior Fixed Ladder, 4th Floor to Roof
(2) 3’x7′ Exterior Steel Door
(1) 3′ x 7′ Interior Steel Door
(9) 3’x4′ Window Openings with Steel Shutters
(1) 2’6″ x 3′ Bilco Roof Hatch
(1) 2nd Floor 6′ x 8′ Inset Balcony

Residential Section

Gable-Roof
Residence

Dimensions	14’L x 16’W x 25’H
Roof	16° Gable
Roof Live Load	100 PSF
Wind Load	Per Local Codes
Deck Live Load	100 PSF

Included

Roof Ladder Fender Brackets
(1) 3′ x 7′ Exterior Steel Door
(3) 3′ x 3′ Window Openings with Steel Shutters
(1) 3′ x 4′ Window Openings with Steel Shutters
(2) 3’x 3′ Hinged Gable Louvers
(2) 4′ x 4′ Roof Chop-Out Curbs
(1) 1st Floor Burn Room
(1) 2nd Floor Maze Room
(1) Westec® Insulation System
(1) Scout Temperature Monitoring System

Accessories

Configure it for the way you train

Balconies

Balcony, Cantilevered

Balcony, Inset

Balcony, Open Corner

Balcony, Supported

Burn Props & Areas

Burn Area, Attic

Burn Area, Corner

Burn Crib

Burn Room

Class A Burn Prop – Bed Simulator

Class A Burn Prop – Bunk Bed Simulator With Burnable Top Bunk

Class A Burn Prop – Bunk Bed Simulator With Enclosed Top Bunk

Class A Burn Prop – Movable Burn Bin

Class A Burn Prop – Stove Simulator With Enclosed Overhead Hood

Class A Burn Prop – Stove Simulator With Overhead Burn Hood

Confined Spaces

Confined Space Rescue Prop

Confined Space Vertical Rescue Prop, Removable

Elevator Shaft (Confined Space)

Manhole Frame/Cover

Doors

Floor Door

Forcible Entry Training System/Door

Heavy-Duty Spring Closer For Burn Room Doors

Ladders

Ladder Hook Bar

Ladder, Caged

Ladder, Interior

Ladder, Ship’s

Rappelling

Rappel Railing

Rappelling Anchor, Swivel

Rappelling Platform

Smoke Systems

Smoke Distribution System

Smoke Generator

Temperature Monitoring

Fire Watchman Pyrometer

Scout Cellular Texting Alarm

Scout External Alarm

Scout External Alarm Horn

Scout Pyrometer with Bluetooth

Moveable Partitions

Movable Half-Wall System/Maze

Movable Wall System/Maze

Movable Wall System/Maze with Working Door

Annunciator Visual/Audio Alarm Panel

Debris Catch Pan

Exhaust Fan

Exterior Stairs (Fire Escape)

Facade, Mortarless Brick

Helicopter Skid Simulator

LPG/Natural Gas Props

Multi-Level Platform

Open Story

Operating Lever Latch

Riser System (Fire Department Connection)

Roll-up Door

Slip-Resistant Paint Roof System

Slip-Resistant Roof Tape

Sprinkler System

Westemp® Insulating Panels

Land Area Requirements

Plan your site

Basic building site	1.00 acre
Drafting pit	0.20 acre
Vehicle extrication pad	0.20 acre
Rail car spill	0.60 acre
Tank truck spill/roll-over	0.20 acre
Flammable liquid pond	0.10 acre
Electric transformer pad	0.10 acre
Aircraft rescue pad	0.70 acre
Classroom building	0.30 acre
Garage	0.30 acre
