The Division Chief

Print

The Division Chief is a 36′ high fire training tower incorporating features from both the Lieutenant and the Assistant Fire Chief. With a footprint spanning 16′ wide x 36′ long, the Division Chief features seven rooms for the ultimate in training. The maze room, comprised of 12 movable, slide-able, and lockable partitions, allows training officers to challenge trainees time after time by redesigning the room into any configuration. The tower’s inset corner balcony offers a secure and realistic area to practice rappelling and laddering.

Request More Information
Product Details
Training Tower
Dimensions 22'L x 16'W x 36'H
Roof Flat
Roof Live Load 100 PSF
Wind Load Per Local Codes
Deck Live Load 100 PSF
  • Parapet Roof Guard with Chained Opening
  • Interior Stair to 4th Floor
  • Interior Fixed Ladder, 4th Floor to Roof
  • (2) 3’x7′ Exterior Steel Door
  • (1) 3′ x 7′ Interior Steel Door
  • (9) 3’x4′ Window Openings with Steel Shutters
  • (1) 2’6″ x 3′ Bilco Roof Hatch
  • (1) 2nd Floor 6′ x 8′ Inset Balcony
Residential Section
Dimensions 14'L x 16'W x 25'H
Roof 16° Gable
Roof Live Load 100 PSF
Wind Load Per Local Codes
Deck Live Load 100 PSF
  • Roof Ladder Fender Brackets
  • (1) 3′ x 7′ Exterior Steel Door
  • (3) 3′ x 3′ Window Openings with Steel Shutters
  • (1) 3′ x 4′ Window Openings with Steel Shutters
  • (2) 3’x 3′ Hinged Gable Louvers
  • (2) 4′ x 4′ Roof Chop-Out Curbs
  • (1) 1st Floor Burn Room
  • (1) 2nd Floor Maze Room
  • (1) Westec® Insulation System
  • (1) Scout Temperature Monitoring System
Land Area Requirements
Basic building site 1.00 acre
Drafting pit 0.20 acre
Vehicle extrication pad 0.20 acre
Rail car spill 0.60 acre
Tank truck spill/roll-over 0.20 acre
Flammable liquid pond 0.10 acre
Electric transformer pad 0.10 acre
Aircraft rescue pad 0.70 acre
Classroom building 0.30 acre
Garage 0.30 acre

Additional allowances should be made for parking, retention ponds, or equipment storage.

Land area requirements vary slightly for different tower models. Please contact us for requirements on your specific project.

Balcony

Balcony, Cantilevered

Balcony, Inset

Balcony, Open Corner

Balcony, Supported

Burn Props and Burn Areas

Burn Area, Attic

Burn Area, Corner

Burn Crib

Burn Room

Class A Burn Prop - Bed Simulator

Class A Burn Prop - Bunk Bed Simulator With Burnable Top Bunk

Class A Burn Prop - Bunk Bed Simulator With Enclosed Top Bunk

Class A Burn Prop - Movable Burn Bin

Class A Burn Prop - Stove Simulator With Enclosed Overhead Hood

Class A Burn Prop - Stove Simulator With Overhead Burn Hood

Confined Spaces

Confined Space Rescue Prop

Confined Space Vertical Rescue Prop, Removable

Elevator Shaft (Confined Space)

Manhole Frame/Cover

Doors

Floor Door

Forcible Entry Training System/Door

Heavy-Duty Spring Closer For Burn Room Doors

Tactical Breach Door

Hatches

Roof Hatch

Ladders

Ladder Hook Bar

Ladder, Caged

Ladder, Interior

Ladder, Ship's

More

Annunciator Visual/Audio Alarm Panel

Debris Catch Pan

Exhaust Fan

Exterior Stairs (Fire Escape)

Facade, Mortarless Brick

Helicopter Skid Simulator

LPG/Natural Gas Props

Multi-Level Platform

Open Story

Operating Lever Latch

Riser System (Fire Department Connection)

Roll-up Door

Slip-Resistant Paint Roof System

Slip-Resistant Roof Tape

Sprinkler System

Westemp® Insulating Panels

Moveable Partitions

Movable Half-Wall System/Maze

Movable Wall System/Maze

Movable Wall System/Maze with Working Door

Pyrometers

Fire Watchman Pyrometer

Scout Cellular Texting Alarm

Scout External Alarm

Scout External Alarm Horn

Scout Pyrometer with Bluetooth

Rappelling

Rappel Railing

Rappelling Anchor, Swivel

Rappelling Platform

Smoke Systems

Smoke Distribution System

Smoke Generator

Fire Facilities offers several color options, including nine durable, prefinished trim colors and four wall colors. The paint finish is multi-coated for long life. A 30/25-year paint warranty is standard with all Fire Facilities training structures.

Note: Colors shown are screen samples, colors vary on actual panel material. For a steel color sample, please complete the Request Form.

Wall Colors
Slate Gray
Iced White
Cream Beige
Classic Beige
Trim Colors
Patrician Bronze
Matte Black
Orange
Desert Tan
Continental Brown
Royal Blue
Cedar Red
Polar Blue
Evergreen
Iced White
Garnet
Training Tower
Dimensions 22'L x 16'W x 36'H
Roof Flat
Roof Live Load 100 PSF
Wind Load Per Local Codes
Deck Live Load 100 PSF
  • Parapet Roof Guard with Chained Opening
  • Interior Stair to 4th Floor
  • Interior Fixed Ladder, 4th Floor to Roof
  • (2) 3’x7′ Exterior Steel Door
  • (1) 3′ x 7′ Interior Steel Door
  • (9) 3’x4′ Window Openings with Steel Shutters
  • (1) 2’6″ x 3′ Bilco Roof Hatch
  • (1) 2nd Floor 6′ x 8′ Inset Balcony
Residential Section
Dimensions 14'L x 16'W x 25'H
Roof 16° Gable
Roof Live Load 100 PSF
Wind Load Per Local Codes
Deck Live Load 100 PSF
  • Roof Ladder Fender Brackets
  • (1) 3′ x 7′ Exterior Steel Door
  • (3) 3′ x 3′ Window Openings with Steel Shutters
  • (1) 3′ x 4′ Window Openings with Steel Shutters
  • (2) 3’x 3′ Hinged Gable Louvers
  • (2) 4′ x 4′ Roof Chop-Out Curbs
  • (1) 1st Floor Burn Room
  • (1) 2nd Floor Maze Room
  • (1) Westec® Insulation System
  • (1) Scout Temperature Monitoring System
Land Area Requirements
Basic building site 1.00 acre
Drafting pit 0.20 acre
Vehicle extrication pad 0.20 acre
Rail car spill 0.60 acre
Tank truck spill/roll-over 0.20 acre
Flammable liquid pond 0.10 acre
Electric transformer pad 0.10 acre
Aircraft rescue pad 0.70 acre
Classroom building 0.30 acre
Garage 0.30 acre

Additional allowances should be made for parking, retention ponds, or equipment storage.

Land area requirements vary slightly for different tower models. Please contact us for requirements on your specific project.
